Product Summary
The Broadcom BCM1112KPBG is a voice over IP CPE engine. It represents a new level of integration for Ethernet Residential Gateway and Stand-Alone Media Terminal Adapter applications.
Features
BCM1112KPBG features: (1)The BCM1112 is the most highly integrated silicon solution for Ethernet Residential Gateway and Stand-Alone Media Terminal Adapter applications; (2)The BCM1112 Integrates: 150-MHz MIPS32 CPU (165 DMIPS) with 8K I-cache and 4K D-cache, Superscalar 108-MHz ZSP DSP with dual-MAC (216 MIPS), 48K instruction and 32K data RAM, Three-port 10/100BASE-T Ethernet switch with 64K buffer memory; (3)0.18u process technology, 1.8/3.3V; (4)1.1W peak, 0.3-0.8W standby modes; (5)256-PBGA package enables 4-layer PCB designs; (6)Pin Compatible with BCM1101.
Diagrams
 |
