Product Summary

The op285gs is a precision high-speed amplifier featuring the Butler Amplifier front-end. This new front-end design combines the accuracy and low noise performance of bipolar transistors with the speed of JFETs. This yields an amplifier with high slew rates, low offset and good noise performance at low supply currents. Bias currents are also low compared to bipolar designs. The applications of the op285gs include High Performance Audio, Active Filters, Fast Amplifiers and Integrators.

Parametrics

op285gs absolute maximum ratings: (1)Supply Voltage: ±22 V; (2)Input Voltage: ±18 V; (3)Differential Input Voltage: ±7.5 V; (4)Output Short-Circuit Duration to Gnd: Indefinite; (5)Storage Temperature Range: –65 to +150℃; (6)Operating Temperature Range: –40 to +85℃; (7)Junction Temperature Range: –65 to +150℃; (8)Lead Temperature Range (Soldering 60 Sec): 300℃.

Features

op285gs features: (1)Low Offset Voltage: 250 μV; (2)Low Noise: 6 nV/√ Hz; (3)Low Distortion: 0.0006%; (4)High Slew Rate: 22 V/μs; (5)Wide Bandwidth: 9 MHz; (6)Low Supply Current: 5 mA; (7)Low Offset Current: 2 nA; (8)Unity-Gain Stable; (9)SO-8 Package.

Diagrams

op285gs pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
OP285GS
OP285GS


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-98: $2.94
OP285GS-REEL
OP285GS-REEL


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-2500: $1.92
OP285GS-REEL7
OP285GS-REEL7


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-1000: $1.94
OP285GSZ
OP285GSZ


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-1: $3.55
1-10: $3.17
10-100: $2.60
100-250: $2.35
250-500: $2.11
500-1000: $1.78
1000-2500: $1.69
OP285GSZ-REEL
OP285GSZ-REEL


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-2500: $1.69
OP285GSZ-REEL7
OP285GSZ-REEL7


IC OPAMP GP 9MHZ DUAL PREC 8SOIC

Data Sheet

0-1000: $1.78
