Product Summary

The NE521G is a High-Speed Dual-Differential Comparator/Sense Amp. The applications of the device are MOS Memory Sense Amp, A-to-D Conversion and High-Speed Line Receiver.

Parametrics

NE521G absolute maximum ratings: (1)Supply Voltage Positive, V+: +7.0V; Negative, V-: -7.0V; (2)Differential Input Voltage VIDR: ±6.0 V; (3)Input Voltage, VIN: ±5.0V; (4)Maximum Power Dissipation, PD: 1420mW; (5)Thermal Resistance, Junction-to-Ambient, RθJA: 100℃/W; (6)Operating Temperature Range TA: 0 to 70℃; (7)Storage Temperature Range Tstg: -65 to +150℃; (8)Operating Junction Temperature TJ: 150℃; (9)Lead Soldering Temperature (10 sec max) Tsld: +230℃.

Features

NE521G features: (1)TTL-Compatible Strobes and Outputs; (2)Large Common-Mode Input Voltage Range; (3)Operates from Standard Supply Voltages; (4)Pb-Free Packages are Available.

Diagrams

NE521G block diagram
