Product Summary
The lmx2306 is a monolithic, integrated frequency synthesizer with prescalers that are designed to be used to generate a very stable low noise signal for controlling the local oscillator of an RF transceiver. It is fabricated using National ABiC V silicon BiCMOS 0.5μ process. The lmx2306 contains a 8/9 dual modulus prescaler. The lmx2306 employs a digital phase locked loop technique. When combined with a high quality reference oscillator and loop filter, the lmx2306 provides the feedback tuning voltage for a voltage controlled oscillator to generate a low phase noise local oscillator signal. Serial data is transferred into the lmx2306 via a three wire interface (Data, Enable, Clock). Supply voltage can range from 2.3V to 5.5V. The lmx2306 features ultra low current consumption; LMX2306TM - 1.7 mA at 3V.
Parametrics
lmx2306 absolute maximum ratings: (1)Power Supply Voltage, VCC1: -0.3V to +6.5V; (2)VCC2: -0.3V to +6.5V; (3)Vp -0.3V to +6.5V; (4)Voltage on Any Pin with GND = 0V (VI): -0.3V to VCC + 0.3V; (5)Storage Temperature Range (TS): -65℃ to +150℃; (6)Lead Temperature (TL)(solder, 4 sec.): +260℃.
Features
lmx2306 features: (1)2.3V to 5.5V operation; (2)Ultra low current consumption; (3)2.5V VCC JEDEC standard compatible; (4)Programmable or logical power dowmode: ICC = 1μA typical at 3V; (5)Dual modulus prescaler: 8/9; (6)Selectable charge pump TRI-STATE mode; (7)Selectable FastLock mode with timeout counter; (8)MICROWIRE Interface; (9)Digital Lock Detect.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
LMX2306 |
Other |
Data Sheet |
Negotiable |
|
||||||
LMX2306SLBX/NOPB |
IC FREQ SYNTH 16LAMINATE CSP |
Data Sheet |
Negotiable |
|
||||||
LMX2306TM/NOPB |
IC FREQ SYNTHESIZER 16-TSSOP |
Data Sheet |
Negotiable |
|
||||||
LMX2306TMX/NOPB |
IC FREQ SYNTH LOW PWR 16-TSSOP |
Data Sheet |
Negotiable |
|
